Description
Clutch Pressure Plate 0011309640 is supplied in new condition. It is listed for 104 machine variants across 2 manufacturers. We ship from stock inside the EU — no import duty, no customs delay, no transatlantic wait.
Listed against original number 0011309640 (RENAULT) for identification and compatibility. This is not a RENAULT-branded product. It is a new part supplied in the producer’s original packaging — the producer is named in the Manufacturer & product safety section below, as Regulation (EU) 2023/988 requires.
Technical specification
| Outer diameter | 280 mm |
|---|---|
| Inner diameter | 280 mm |
| Pressure plate type | two-disc |
| Number of cuts | 16 |
| Number of levers | 6 |
| Weight | 28.14 kg |
| Country of origin | Poland |
| Clutch | for vehicles with double disc clutch |
| Technical Information Number | TGU6 |
Vehicle and machine applications (104)
Fits equipment from 2 manufacturers: JOHN DEERE, RENAULT.
| Make | Model | Engine | Engine code | Years | kW | hp | ccm |
|---|---|---|---|---|---|---|---|
| JOHN DEERE | 3000 | 3100 | 4039DRT65, 3029D | 1995/01 – 1998/12 | 41 | 56 | 2940 |
| JOHN DEERE | 3000 | 3100 A | 4039DRT65, 3029D | 1995/01 – 1998/12 | 41 | 56 | 2940 |
| JOHN DEERE | 3000 | 3110 | 3179 | 1998/01 – 2001/12 | 40 | 55 | 2940 |
| JOHN DEERE | 3000 | 3110 A | 3179 | 1998/01 – 2001/12 | 40 | 55 | 2940 |
| JOHN DEERE | 3000 | 3200 | 4039D, 4039DRT35 | 1995/01 – 1998/12 | 48 | 65 | 3920 |
| JOHN DEERE | 3000 | 3200 A | 4039D, 4039DRT35 | 1995/01 – 1998/12 | 48 | 65 | 3920 |
| JOHN DEERE | 3000 | 3200 AX | 4039DRT35 | 1994/01 – 1998/12 | 48 | 65 | 3920 |
| JOHN DEERE | 3000 | 3200 X | – | 1994/01 – 1998/12 | 48 | 65 | 3920 |
| RENAULT | 600 | 650 MI | – | n/a – n/a | — | — | — |
| RENAULT | CERES | 310 | 3029D | 1998/01 – 2001/12 | 40 | 55 | 2940 |
| RENAULT | CERES | 65 | – | 1993/01 – 1998/12 | 40 | 55 | 2940 |
| RENAULT | CERES | 65 | D 226-3 | 1993/01 – 1995/12 | 40 | 54 | 3117 |
| RENAULT | CERES | 70 2WD | – | n/a – n/a | — | — | — |
| RENAULT | CERES | 70 4WD | – | n/a – n/a | — | — | — |
| RENAULT | CERES | 70 X | D 226-3 | 1993/01 – 1995/12 | 44 | 60 | 3117 |
| RENAULT | CERES | 70 X | – | n/a – n/a | — | — | — |
| RENAULT | CERES | 75 | 4.236 | 1993/01 – 1995/12 | 48 | 65 | 3900 |
| RENAULT | CERES | 75 | 4039DRT35 | 1994/01 – 1998/12 | 48 | 65 | 3900 |
| RENAULT | CERES | 75 X | 4.236 | 1994/01 – 1998/12 | 48 | 65 | 3920 |
| RENAULT | CERES | 75 X | A4.236 | 1993/01 – 1995/12 | 48 | 65 | 3864 |
| RENAULT | XX-12 | 58-12 LS | D 226-3 | n/a – n/a | — | — | — |
| RENAULT | XX-12 | 61-12 RA | – | n/a – n/a | — | — | — |
| RENAULT | XX-12 | 61-12 RS | – | n/a – n/a | — | — | — |
| RENAULT | XX-12 | 65-12 LS | D 226-3 | 1985/01 – 1989/12 | 44 | 60 | 3117 |
| RENAULT | XX-12 | 68-12 RA | – | n/a – n/a | — | — | — |
| RENAULT | XX-12 | 68-12 RS | D 227-4 | 1983/01 – 1987/12 | 50 | 68 | 3770 |
| RENAULT | XX-12 | 70-12 SP | 4.236, F 4L 913, F 4L 912 | n/a – n/a | — | — | — |
| RENAULT | XX-12 | 75-12 LS | D 226-4 | 1985/01 – 1989/12 | 51 | 70 | 4156 |
| RENAULT | XX-12 | 75-12 RA | – | n/a – n/a | — | — | — |
| RENAULT | XX-12 | 75-12 RS | D 226-4 | 1983/01 – 1987/12 | 55 | 75 | 4156 |
| RENAULT | XX-12 | 75-12 TS | D 226-4 | 1982/01 – 1984/12 | 55 | 75 | 4156 |
| RENAULT | XX-12 | 77-12 TS | D 226-4 | 1986/01 – 1989/12 | 51 | 70 | 4156 |
| RENAULT | XX-12 | 80-12 SP | 4.248, D 226-4 | n/a – n/a | — | — | — |
| RENAULT | XX-12 | 80-12 TX | 4.248, D 226-4 | 1984/01 – 1987/12 | 57 | 78 | 4156 |
| RENAULT | XX-12 | 85-12 LS | D 226-4 | 1985/01 – 1989/12 | 57 | 78 | 4156 |
| RENAULT | XX-12 | 85-12 TS | D 226-4 | 1986/01 – 1989/12 | 57 | 78 | 4156 |
| RENAULT | XX-12 | 85-12 TX | D 226-4 | 1986/01 – 1989/12 | 57 | 78 | 4156 |
| RENAULT | XX-14 | 58-14 LS | D 226-3 | n/a – n/a | — | — | — |
| RENAULT | XX-14 | 61-14 RA | – | n/a – n/a | — | — | — |
| RENAULT | XX-14 | 61-14 RS | – | n/a – n/a | — | — | — |
| RENAULT | XX-14 | 65-14 LS | D 226-3 | 1985/01 – 1989/12 | 44 | 60 | 3117 |
| RENAULT | XX-14 | 68-14 RA | – | n/a – n/a | — | — | — |
| RENAULT | XX-14 | 68-14 RS | D 227-4 | 1983/01 – 1987/12 | 50 | 68 | 3770 |
| RENAULT | XX-14 | 70-14 SP | 4.236, F 4L 913, F 4L 912 | n/a – n/a | — | — | — |
| RENAULT | XX-14 | 75-14 LS | D 226-4 | 1985/01 – 1989/12 | 51 | 70 | 4156 |
| RENAULT | XX-14 | 75-14 RA | – | n/a – n/a | — | — | — |
| RENAULT | XX-14 | 75-14 RS | D 226-4 | 1983/01 – 1987/12 | 55 | 75 | 4156 |
| RENAULT | XX-14 | 75-14 TS | D 226-4 | 1982/01 – 1984/12 | 55 | 75 | 4156 |
| RENAULT | XX-14 | 77-14 TS | D 226-4 | 1986/01 – 1989/12 | 51 | 70 | 4156 |
| RENAULT | XX-14 | 80-14 SP | 4.248, F 4L 913, D 226-4, F 4L 912 | n/a – n/a | — | — | — |
| RENAULT | XX-14 | 80-14 TX | 4.248, F 4L 913, D 226-4, F 4L 912 | 1984/01 – 1987/12 | 57 | 78 | 4156 |
| RENAULT | XX-14 | 85-14 LS | D 226-4 | 1985/01 – 1989/12 | 57 | 78 | 4156 |
| RENAULT | XX-14 | 85-14 TS | D 226-4 | 1986/01 – 1989/12 | 57 | 78 | 4156 |
| RENAULT | XX-14 | 85-14 TX | D 226-4 | 1986/01 – 1989/12 | 57 | 78 | 4156 |
| RENAULT | XX-32 | 58-32 MA | D 226-3 | 1989/01 – 1993/12 | 40 | 54 | 3117 |
| RENAULT | XX-32 | 58-32 ME | – | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 58-32 MS | – | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 58-32 MX | – | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 65-32 MA | D 226-3 | 1989/01 – 1993/12 | 44 | 60 | 3117 |
| RENAULT | XX-32 | 65-32 ME | – | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 65-32 MS | – | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 65-32 MX | – | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 70-32 PA | 4.236 | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 70-32 PE | 4.236 | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 70-32 PS | 4.236 | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 70-32 PX | 4.236 | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 75-32 MA | D 226-4 | 1989/01 – 1993/12 | 51 | 70 | 4156 |
| RENAULT | XX-32 | 75-32 ME | – | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 75-32 MS | – | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 75-32 MX | – | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 75-32 TX | D 226-4 | 1989/01 – 1993/12 | 57 | 78 | 4156 |
| RENAULT | XX-32 | 80-32 PA | 4.248 | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 80-32 PE | 4.248 | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 80-32 PS | 4.248 | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 80-32 PX | 4.248 | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 85-32 MA | D 226-4 | 1989/01 – 1993/12 | 57 | 78 | 4156 |
| RENAULT | XX-32 | 85-32 ME | – | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 85-32 MS | – | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 85-32 MX | – | n/a – n/a | — | — | — |
| RENAULT | XX-32 | 85-32 TX | – | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 58-34 MA | D 226-3 | 1989/01 – 1993/12 | 40 | 54 | 3117 |
| RENAULT | XX-34 | 58-34 ME | – | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 65-34 MA | D 226-3 | 1989/01 – 1993/12 | 44 | 60 | 3117 |
| RENAULT | XX-34 | 65-34 ME | – | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 65-34 MS | – | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 65-34 MX | – | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 70-34 PA | 4.236, A4.236 | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 70-34 PE | 4.236, A4.236 | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 70-34 PS | 4.236, A4.236 | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 70-34 PX | 4.236, A4.236 | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 75-34 MA | D 226-4 | 1989/01 – 1993/12 | 51 | 70 | 4156 |
| RENAULT | XX-34 | 75-34 ME | – | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 75-34 MS | – | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 75-34 MX | – | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 75-34 TX | D 226-4 | 1989/01 – 1993/12 | 57 | 78 | 4156 |
| RENAULT | XX-34 | 80-34 PA | 4.248 | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 80-34 PE | 4.248 | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 80-34 PS | 4.248 | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 80-34 PX | 4.248 | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 85-34 MA | D 226-4 | 1989/01 – 1993/12 | 57 | 78 | 4156 |
| RENAULT | XX-34 | 85-34 ME | – | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 85-34 MS | – | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 85-34 MX | – | n/a – n/a | — | — | — |
| RENAULT | XX-34 | 85-34 TX | – | n/a – n/a | — | — | — |
OEM part number equivalent (4)
This part is listed as the equivalent of the original numbers below. If your machine’s parts book shows any of these, this is the item you need.
| Number | Brand |
|---|---|
| 0011309640 | RENAULT |
| 77 00 032 701 | RENAULT |
| 7700 032 701 | JOHN DEERE |
| RT7700032701 | JOHN DEERE |
