Description
Starter 296192300 is supplied in new condition, rated 12 V / 3 kW. It is listed for 23 machine variants across 4 manufacturers. We ship from stock inside the EU — no import duty, no customs delay, no transatlantic wait.
Listed against original number 296192300 (SAME) for identification and compatibility. This is not a SAME-branded product. It is a new part supplied in the producer’s original packaging — the producer is named in the Manufacturer & product safety section below, as Regulation (EU) 2023/988 requires.
Technical specification
| Voltage | 12 V |
|---|---|
| Rated power | 3 kW |
| Rotation direction | clockwise |
| Flange diameter | 82.5 mm |
| Number of teeth | 9 |
| Status | New |
| Weight | 13.82 kg |
| Country of origin | Poland |
| Mounting Angle [degrees] | 35 |
| Number of mounting bores | 2 |
| Packaging height [cm] | 14.5 |
| Packaging width [cm] | 21.5 |
| Packaging length [cm] | 38.2 |
Vehicle and machine applications (23)
Fits equipment from 4 manufacturers: ALLIS CHALMERS, CASE IH, CASE-STEYR, SAME.
| Make | Model | Engine | Engine code | Years | kW | hp | ccm |
|---|---|---|---|---|---|---|---|
| ALLIS CHALMERS | 6000 | 6670 | 1000.4 A | 1991/01 – 1999/12 | — | — | — |
| ALLIS CHALMERS | 6000 | 6680 | 1000.4 A | 1991/01 – 1999/12 | — | — | — |
| ALLIS CHALMERS | 6000 | 6690 | 1000.4 AT | 1991/01 – 1997/12 | — | — | — |
| CASE IH | 2000 | 2140 | – | 1991/01 – 1991/12 | 46 | 62 | 4000 |
| CASE IH | 2000 | 2150 | – | 1991/01 – 1991/12 | 50 | 68 | 4000 |
| CASE-STEYR | 8000 | 8100 | WD 411 | 1978/12 – n/a | 63 | 86 | — |
| CASE-STEYR | 8000 | 8100 A | WD 611.40 | 1978/12 – 1988/12 | 63 | 86 | — |
| CASE-STEYR | 8000 | 8110 | – | 1978/12 – n/a | 66 | 90 | — |
| CASE-STEYR | 8000 | 8110 A | – | 1984/06 – n/a | 66 | 90 | — |
| CASE-STEYR | 8000 | 8120 | WD 411 | 1980/01 – n/a | 74 | 101 | — |
| CASE-STEYR | 8000 | 8120 A | – | 1980/01 – n/a | 74 | 101 | — |
| CASE-STEYR | 8000 | 8130 | – | 1984/06 – n/a | 81 | 110 | — |
| CASE-STEYR | 8000 | 8130 A | WD 611.87 | 1984/06 – n/a | 81 | 110 | — |
| SAME | ANTARES | 100 | 1000.4 ATI | 1989/01 – 1995/01 | 74 | 101 | 4000 |
| SAME | ANTARES | 110 | 1000.6 A | 1991/01 – 1996/01 | 81 | 110 | 6000 |
| SAME | ANTARES | 130 | 1000.6 AT | 1991/01 – 1996/01 | 96 | 130 | 6000 |
| SAME | ANTARES | 130 T | 1000.6 AT | 1990/01 – 1998/12 | 93 | 127 | — |
| SAME | ANTARES II | 110 | 1000.6 A | 1996/01 – 2000/01 | 81 | 110 | 6000 |
| SAME | ANTARES II | 110 | 1000.6 AT | 1996/01 – 2000/01 | 93 | 127 | 6000 |
| SAME | ANTARES II | 130 | 1000.6 AT | 1996/01 – 2000/01 | 93 | 127 | 6000 |
| SAME | DORADO 1 / 2 | 70 | 1000.4 A5 | 1990/01 – 2000/01 | 52 | 71 | 4000 |
| SAME | DORADO 3 | 70 | 1000.3WT | 2009/09 – n/a | 55 | 75 | 3000 |
| SAME | DORADO 3 | 80 | 1000.3WT, 1000.3 WTI2 | 2009/09 – n/a | 60 | 82 | 3000 |
OEM part number equivalent (6)
This part is listed as the equivalent of the original numbers below. If your machine’s parts book shows any of these, this is the item you need.
| Number | Brand |
|---|---|
| 296192300 | SAME |
| 296193500 | SAME |
| 296193800 | SAME |
| C000900060040 | AGCO |
| 6005706618 | CLAAS |
| CT6005706618 | CLAAS |
Shipping and warranty
We dispatch within 1–4 business days of payment. The exact dispatch date is shown at checkout. Prices include 21 % VAT; the price without VAT is shown next to it. Business customers from another EU country with a valid VAT number pay 0 % VAT at checkout. Consumers have the statutory two-year EU warranty; business customers have our 12-month warranty — see Returns and refunds.
